Description
The testo 470 dual function tachometer is the ideal combination of optical and mechanical rpm measurement.
Non-Contact Optical Measurement: easily measure rpm by simply attaching a reflector to the object to be measured, point the visible, red light beam at the reflector and measuring.
Mechanical Measurement: an optical measurement becomes a mechanical measurement by simply attaching an adapter for a probe tip or surface speed disk.
Measure rpm, speeds and lengths Selectable Units: rpm, U/min, m/min, ft/min, in/min
Easy one-hand operation Auto off after 30 seconds Min/Max, mean & last measure value saved “Low Batt” warning
Production processes are not interrupted
Applications RPM measurement of shafts RPM measurement of rollers Turbine and pump Fan installations Roller speed-length measurements Measure speed of production conveyor belts
testo 470 Technical Specifications |
||
Probe Type | Optically with mod light beam | Mechanical |
Display | 5-figure LCD display, 1 line | |
Measuring Range | 1 to 99999 rpm | 1 to 19.999 rpm |
Measurement Distance | 23.62 inches / 60 cm | |
Resolution | ±0.01 rpm (+1… +99.99 rpm) ±0.1 rpm (+100…+999.9 rpm) ±1 rpm (+1000…99999 rpm) |
|
Accuracy | ±0.02% of measured value + 1 digit | ±0.02% of measured value + 1 digit |
Sensor | Optically with modulated light beam | |
Auto Off | 30 seconds (mean, maximum and last value measured are saved) | |
Storage temperature | -4 to +158 °F / -20 to +70 °C | |
Operating temperature | +32 to +123 °F / 0 to 50 °C | |
Battery type | 2 AA batteries, 1.5 v batteries | |
Battery Life | 40 hours | |
Weight | 5.08 oz / 190 grams
|
|
Shipping Weight | approximately 3 lbs | |
Dimensions | 6.9 x 2.4 x 1.1 inches 175 x 60x 28mm |
|
Warranty | 2 years |
testo 470 Accessories |
||
Part # |
Description
|
|
0563 0470 | testo 470 Dual Function Tachometer Instrument in soft case in transport case incl. probe tip, 0.1 m and 6″ wheel, reflectors and batteries |
|
0554 0493 | Reflectors, self-adhesive (1 pack = 5 off, each 150 mm long) | |
0554 4754 | Measuring wheel 6″ | |
0554 4755 | Measuring wheel 12″ |
Additional information
Weight | 1 kg |
---|
